Pipe Bender RDB-150

Product image is only a representation, actual product appearance may differ slightly

  • Pipe Bender RDB-150
  • Pipe Bender RDB-150as
  • Pipe Bender RDB-150as
  • Pipe Bender RDB-150as
  • Pipe Bender RDB-150asPipe Bender RDB-150as
  • Pipe Bender RDB-150as
  • Pipe Bender RDB-150as
  • Pipe Bender RDB-150as

Description

In 2002, Baileigh broke new ground for hydraulic benders with the RDB-150—and we didn’t stop there! Made in the USA, this aluminum pipe bender model improves on the original with an added auto-stop feature, for even more exacting standards.


  • Powerful low-pressure hydraulic system operates on only 110 volts.
  • Tackles a maximum capacity of 2” schedule 40 pipe and up to 2.5” tubing with a wall thickness of .120” mild steel.
  • Executes consistent 180° bends in one fluid motion.
  • Auto-stop programmer lets you set the desired bend angle for convenient precision and repeatability.
  • Quick-release counter die makes for fast loading and unloading.
  • Easy-to-read degree indicator shows a bend’s progress.
  • Compact machine includes wheels on the base for convenient storage in small shops.
  • Covered by a 1-year parts warranty.
  • Includes lifetime technical support form from our experienced team of representatives.

Use this machine for: Creating custom chassis, handrails, boilers, and metal art, among other projects.


Why choose the RDB-150-AS over comparable machines?


  • It’s the best buy in hydraulic pipe benders today, designed to make your fabrication shop more efficient.
  • Comes standard with auto-stop to save time and cut down on errors.
  • Accepts quality “drop-on” tooling from Baileigh, providing thousands of options for your application—many more than “sandwiched” tooling could offer.
  • Limitless after-sale support and advice on projects are just a phone call away.

Feel free to call us at 1-920-684-4990 to talk to a customer service representative or fill out our contact form.


Sample Tooling List

Discount Tooling Packages


Read More Read Less

Specifications

Item Number RDB-150-AS
Country of Manufacture United States
Minimum CLR .5"
Minimum OD .25"
Mild Steel Solid Rod 1.25"
Mild Steel Pipe Schedule 40 2"
Mild Steel Round Tube Wall 2.5" (.125)
Mild Steel Square Tube (Wall) 2" (.125)
Stainless Steel Pipe Schedule 40 1.5"
Stainless Steel Round Tube Wall 2.375" (.125)
Chromolly Round Tube Wall 2" (.125)
Aluminum Round Tube Wall 2.5" (.156)
Maximum Center Line Radius Clr *7 - 8"
Power 110V
Shipping Weight 610lbs
Special Notes Tooling not included, contact Baileigh at 920-684-4990 for correct sizing.
Shipping Dimensions (Inches) 60x44x77

* specifications subject to change without notice.

California Proposition 65

California Proposition 65

Click HERE for More Information

Stories & Testimonials

Tough Equipment Made to Withstand Extreme Conditions

Brad Mandery of KM Chassis recently purchased a second-hand RDB-150AS from a company that had a major fire 5 years ago. The fire wiped out the manufacturing facility, but our high-quality bender made it out unharmed and fully-functional!

Read the full story

Makes the job easier!

I purchased the RDB-150-AS pipe bender, and the BS-260M band saw. They sure have made our job easier, quicker, and more profitable. I definitely would recommend their products."

A.W. Stiles Contractors

Makes the job easier!

I purchased the RDB-150-AS pipe bender, and the BS-260M band saw. They sure have made our job easier, quicker, and more profitable. I definitely would recommend their products."

A.W. Stiles Contractors

Q & A

Q. What Tooling is right for you?

A. Baileigh Industrial makes tooling for just about every application possible of rotary draw bending. For this reason, it is important to understand what material you are bending to get the correct die set for your application. Click either link below for a simple description of our tooling to aid you in making this determination.

What is the difference between Pipe and Tube? Click here

What is center line radius? Click here


Pipe Bender RDB-150-AS

SKU: 1006779

In stock

USA Made

$6,795.00 $
Leasing starts at $152 . Calculate your monthly lease price
